⇨ 2800*360 mm Sliding table
⇨ 2800 mm Gross cut capacity
⇨ Main saw dia ; 300mm, scoring saw ; 120mm
⇨ Main motor power & RPM ; 5.5 kw/7 HP & 4500/6000 rpm
⇨ Vice motor power & RPM ; 0.75 KW & 8000 rpm
⇨ 1250 mm width of cut between saw blade and rip fence
⇨ 850 Kg weight
⇨ 3000*3150*900 mm overall dimension
⇨ Horizontal style
⇨ 3000*360 mm Sliding table
⇨ 3000 mm Gross cut capacity
⇨ Main saw dia ; 300mm, scoring saw ; 120mm
⇨ Main motor power & RPM ; 5.5 kw/7 HP & 4500/6000 rpm
⇨ Vice motor power & RPM ; 0.75 KW & 8000 rpm
⇨ 1250 mm width of cut between saw blade and rip fence
⇨ 850 Kg weight
⇨ 3200*3150*900 mm overall dimension
⇨ Horizontal style
⇨ 3200*360 mm Sliding table
⇨ 3200 mm Gross cut capacity
⇨ Main saw dia ; 300mm, scoring saw ; 120mm
⇨ Main motor power & RPM ; 5.5 kw/7 HP & 4500/6000 rpm
⇨ Vice motor power & RPM ; 0.75 KW & 8000 rpm
⇨ 1250 mm width of cut between saw blade and rip fence
⇨ 850 Kg weight
⇨ 3400*3150*900 mm overall dimension
⇨ Horizontal style
A subsidiary of VTP groups which has been in the Trading field since 1969. Having attained a vast knowledge in the field of wood related works
